EC52, ESCALATOR AND TRAVELATOR CLEANER

---

ماكينة غسيل السلالم الكهربائية الأوتوماتيكية

EC52, ESCALATOR AND TRAVELATOR CLEANER

Technical Data:

• Cleaning path 510 mm
• Hourly performance 1.000 m²/h
• Solution tank capacity 35 L
• Recovery tank capacity 35 L
• Motor 230 V / 50-60 Hz
• Brush motor 900 W
• Vacuum motor 1.200 W
• Water pick-up 2.100 mm H2O
• Brush diameter 115 mm
• Squeegee length 780 mm
• Brush speed 400 rpm
• Brush pressure 30 kg
• Weight - without brushes 109 kg
• Dimensions – without squeegee (l x w x h) 1200 x 580 x 920 mm

The EC52 cleans escalators and moving walkways using both a dry and wet cleaning cycle.

It is ideal for both everyday cleaning and to remove engrained dirt and heavier marks.

The revolutionary double brush system guarantees results and once in position, the EC52 works automatically, leaving the operator free to dedicate their time to other tasks.

The new stainless-steel vacuum chamber, furthermore maximizes pick up of water, leaving the steps clean and dry.

The new solution and recovery tanks, with greater capacity, provide more cleaning time, reducing the need to stop and refill during operation and eliminating associated downtime.

The EC52 cleans escalators and moving-walkways, of any brand, with a width of 51cm or greater. It isn’t necessary to stop the escalator to clean with the EC52, and a cleaning cycle is completed in a matter of minutes.

Edge2Edge® technology guarantees perfect cleaning even at the edges of the steps. The brush deck, which rotates 180 degrees, is fitted with thin spacers, allowing it to be placed in direct contact with the escalator’s side panel.

Despite the multiple functions and high performance offered by the EC52, it remains a compact machine, making it easy to transport on its wheels and to be lifted via the pull-out handles.
